VERSADRIVE SC-26X is a 2-in / 6-out signal processor from our VERSADRIVE Series, delivering advanced system control, protection and tuning for live sound and installed audio systems.
| Inputs | 2 |
| Outputs | 6 |
| Input Type | Analog |
| Input Connections | XLR |
| Output Connections | XLR |
| Input Impedance | Balanced : 20 KΩ |
| Output Impedance | Balanced : 100 KΩ |
| Input Effects | Gain, Mute, Link, High-pass filter, Low-pass filter, Noise Gate, 8-band parametric EQ, 31 band graphic EQ, Phase, Delay |
| Output Effects | Crossover, 5-band parametric EQ, Gain, Mute, Compressor / Limiter, Phase, Delay , Linking |
| Input Range | ≤ +16.3 dBu |
| Frequency Response | 19.7 Hz – 20 KHz (+/- 0.5 dB) |
| PC Port | Yes |
| CMRR | >70 dB (1 KHz) |
| SNR | >104 dB |
| THD+N | < 0.01% (Output = 0 dBu / 1 KHz) |
| Channel Separation | > 100 dB (1 KHz) |
| Processor | 32-bit |
| AD/DA Converter | 24-bit, 96 KHz |
| Software Included | Yes |
| Ethernet | Yes |
| Impedance | Balanced : 100 KΩ |
| Display Type | 2 x 24 LCD backlight display. 5-band LED display. Mute / Editing status |
| Password Protected | Yes |
| Main Power | AC 110 V / 220 V 50 / 60 Hz |
| Included Accessory | Power Cable, User Manual |
