| Specifications: | |
| APPLICATION | Low-Middle |
| Nominal impedance | 8 Ohm |
| Power handling IEC noise | 325W |
| Sensitivity(1W/1m) | 98dB |
| Frequency response | 48-3KHz |
| Voice coil diameter | 75.55mm |
| Voice coil material | Copper |
| Voice coil winding depth | 17.5mm |
| Magnet gap depth | 10mm |
| Basket | Aluminum |
| Effect. diaphragm diameter | 130mm |
| MOUNTING INFORMATION | |
| Overall diameter | φ383mm |
| Mounting holes diameter | 8×(φ7×8)mm |
| Bolt circle diameter | 370.5mm |
| Baffle cut-out diameter | 351.5mm |
| Overall depth | 166mm |
| Net weight | 8.05Kg |
| THILE -SMALL PARAMETERS: | ||
| Resonance frequency | Fs | 48Hz |
| DC resistance | Re | 5.6Ohm |
| Mechanical Qfactor | Qms | 3.963 |
| Total Quality factor | Qes | 0.299 |
| Electriacl Q factor | Qts | 0.278 |
| Equivalent volume | Vas | 183.877 L |
| Moving mass | Mms | 0.088Kg |
| Mechanical compl | Cms | 0.177mm/N |
| BLfactor | BL | 20.264 Tesla m |
| Effective piston area | Sd | 0.09 mm |
| Max. linear excursion | Xmax | ±3.75mm |
